125~150 cpm Outsole Flex Tester Machines , Large Bottom Bend Test Machine

Name: 125150 cpm Outsole Flex Tester Machines Large Bottom Bend Test Machine
Brand: YUYANG
Price: 500.00 USD

125~150 cpm Outsole Flex Tester Machines , Large Bottom Bend Test Machine Manufactures

Brand Name : YUYANG

Model Number : YY1505

Certification : GB/T3903.2

Place of Origin : China

MOQ : 1

Price : $500.00

Payment Terms : Western Union, T/T, L/C,Paypal

Supply Ability : 4pcs /week

Delivery Time : 8-10days

Packaging Details : Plywood case

Weight : 98KG

Packing : Plywood case

Power : 1∮﹐AC 220V, 3A (Specified by user)

Testing speed : 125~150cpm

Product Name : Footwear Testing Equipment

Usage : Outsole Flexing Tester

Sampling : 3 pcs

Dimension : 100×53×30 cm

Contact Now

125~150cpm Outsole Flexing Tester Large Bottom Bending Footwear Testing Equipment

Description:

This machine is designed Tor flexing soles repeatedly. The specimen is mounted between two clamps and let the flexing axle pass through the cut on the specimen. When testing, the specimen is flexed at a specified angle for a given number, and then the length of cut growth is measured. This machine has the returning function, so it is convenient and time saving.

Parameters:

Displacement of moveable clamp	41.5±0.5mm
Diameter of moveable flexing axle	30 ± 1mm
Speed	125~150cpm
Flexing Angle	90°
Sampling	3 pcs
Counter	LCD,0～99,999,999
Dimension(W×D×H)	100×53×30 cm
Weight	98kg
Power	1∮﹐AC 220V, 3A (Specified by user)
